With fastening element |
Easily mountable and extractable from the load side |
Fixing is by means of spring clips, which permit generous tolerances in the mounting hole |
Reinforced cover to withstand heavy impact loads |
Ball cup and ball retaining ring made from corrosion-resistant steel, other parts galvanized |
Balls made from 1.3541 / 1.4034 |
With bottom hole |
Data Sheet | Download Data Sheet |
2D CAD | Download 2D CAD |
2D CAD | Download 2D CAD |
3D CAD | Download 3D CAD |
3D CAD | Download 3D CAD |
Tolerance DB | |
Productgroup ID | 17 |
Size b | 8.2 |
Maximum operating temperature | |
Size H | 37.2 |
Minimum operating temperature | |
Size h | 13.8 |
Outer diameter D | 45 |
Maximum permissible linear speed vmax | 2 |
Operating temperature | -30 °C ... +100 °C |
Size D | 45 |
Size D1 | 55 |
Tolerance h | |
Static load rating C0 | 3500 |
Footnote permissible operating temperature (min...max) | At temperatures above 100 °C, only bright metal ball transfer units without a felt seal should be used. Make allowance for reduction in load capacity. Use high-temperature lubricant! Follow the manufacturer’s instructions! The existing lubricant oil may have to be washed out. |
Size s | 2.5 |
Dynamic load capacity C | 1900 |
Size DB | 45 |
Footnote operating temperature max. | For temperatures over 100°C, only load balls made from bare metal without a felt seal may be used. Take into account the reduction in load capacity. Use high-temperature lubricant! Follow the instructions of the manufacturer! The existing lubricant oil may have to be washed out. |
Note: Maximum permissible speed vmax | In case of prolonged periods of use at speeds above 1 m/s, an increase in temperature and reduction in service life needs to be reckoned with depending on the load. |
Size dW | 30.162 |
Weight | 0.289 |
Tolerance D | |
Nominal size | 30 |
