LOCATING RING D=16 ...

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LOCATING RING (R039660546) is a highly precise mechanical accessory designed to facilitate the mounting of customer attachments to a frame with exceptional accuracy and stability. This centering ring falls under the product group of mechanical accessories for linear axes, specifically within the category of centering rings. With its nominal size and an outer diameter D of 16, it is engineered to serve as a positioning aid that ensures positive locking with good reproducibility. Constructed from durable steel, the LOCATING RING exhibits robustness and longevity. It is manufactured to adhere to specific tolerance levels, with a Tolerance C denoted by prefixprefix.suffixsuffix and a Tolerance D also specified by prefixprefix.suffixsuffix, ensuring that it meets stringent quality standards for precision fitting. The Size D and Size C dimensions are meticulously crafted to fit seamlessly into the intended applications, while the Size H dimension further specifies its fitment characteristics. The ring's primary capability lies in creating a positive-locking connection that can be reliably reproduced, which is vital for maintaining consistency in applications where precision alignment is crucial. Its weight specification contributes to its ease of handling and installation without compromising on the structural integrity or performance once in place. In summary, the Bosch Rexroth LOCATING RING is an essential component for users requiring high-precision mounting solutions within linear motion systems or similar applications where exact positioning and secure attachment are paramount.
