LOCATING RING D=12/7 ...

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LOCATING RING (R039660577) is a high-precision mechanical accessory designed for linear axes applications. This centering ring belongs to the product group of mechanical accessories and is specifically categorized under centering rings of size E. The ring features an outer diameter (D) that conforms to exact specifications, ensuring a perfect fit for the required applications. With a nominal size tailored for precision, the LOCATING RING is manufactured from robust steel material, offering durability and long-lasting performance. This Bosch Rexroth component is engineered to facilitate precise positioning and positive locking when attaching customer components to a frame. It boasts excellent reproducibility, which means that it can consistently create the same quality of connection each time it is used. The LOCATING RING's tolerance levels are meticulously defined with a C prefix for size E and a D prefix for outer diameter measurements, emphasizing its role in applications that demand high accuracy and reliability. The weight of the ring has been optimized to contribute to the overall efficiency of the assembly without compromising on strength or functionality. Size C and H dimensions are also provided to ensure compatibility with various mounting scenarios. The Bosch Rexroth LOCATING RING serves as an essential element in systems requiring precise alignment and secure locking mechanisms, reflecting Bosch Rexroth's commitment to engineering excellence in components for linear motion technology.
