CONNECTING PLATE CKR 25-200 K BG

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CONNECTING PLATE CKR 25-200 K (R037560016) is a specialized mechanical accessory designed for linear axes, specifically to facilitate the secure fastening of attachments using sliding blocks. This connection plate is part of Bosch Rexroth's comprehensive range of components for linear motion technology and is engineered to enable the lubrication of both the ball rail system and the ball screw assembly, which can be accessed via the plate itself. It's compatible with lube versions LSS and LPG, ensuring that maintenance and performance optimization can be carried out effectively. The product comes in a Size A from its product group identification, with other dimensions such as Size E, Size H, and Size D detailed in its specifications to ensure compatibility and precise fitment with corresponding CKR carriages. The nominal size is also provided to assist with integration into various applications. Included in the assembly are not only the connection plate itself but also mounting accessories required for fastening it to carriages. Its design allows for a streamlined installation process, enhancing overall efficiency in assembly operations. The Bosch Rexroth CONNECTING PLATE CKR 25-200 K is integral in creating a robust and reliable connection within linear motion systems. Its construction ensures durability while providing necessary support for attachments, thereby extending the functionality of linear axes in various applications. The weight specification further assists purchasers and engineers in considering design constraints and load capacities when incorporating this component into their systems.
