3842547906

SUPPORTING STRUCTURE 160-320+ STS 1X3024

Manufacturer: Bosch Rexroth

Material #: 3842547906

Model : SUPPORT. STRUCTURE 160-320+ STS 1X3024


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SUPPORT.STRUCTURE 160-320+ STS 1X3024 (3842547906) is a robust and versatile support profile designed for constructing conveyor sections and other structural applications. This product, part of the VFplus STS series, is delivered as a single rod in standard lengths, ensuring compatibility with various project requirements. The support profile boasts an area moment of inertia in the y-direction (ly) and x-direction (lx), indicative of its high bending stiffness and stability under load. Crafted from non-rusting steel, the SUPPORT.STRUCTURE 160-320+ STS 1X3024 is durable and suitable for environments where cleanliness and resistance to corrosion are paramount. Its open construction allows for easy removal of dirt or foreign particles, maintaining the integrity of the system in which it is integrated. The product's uniform profile cross-section across all sizes ensures consistent performance and ease of assembly. For larger configurations starting from size 160, this support profile becomes essential, attaching directly to cross connectors that link two open section profiles to form a stable base for conveyor sections. It features elongated holes strategically placed for the attachment of drive/return units, curves, lateral guides, leg sets, or other accessories. The design simplifies cleaning processes and promotes straightforward maintenance. The Bosch Rexroth SUPPORT.STRUCTURE also includes options for secure connections with accessory parts through plug-through stainless steel T-nuts that offer mounting flexibility on the section profile. However, it is important to note that MGE T-nuts are not compatible with this STS section profile. Overall, this Bosch Rexroth support profile is a standard element in creating strong connections within various structural configurations while providing ease of assembly and maintenance due to its thoughtful design features.

$196.12 USD

Availability:  4  In Stock
  Add to Cart
Available for immediate shipment

Qty: Delivered as early as November 25, 2024 when ordered in
