SUPPORTING STRUCTURE 160-320+ STS 12X3024

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SUPPORT.STRUCTURE 160-320+ STS 12X3024 (3842546700) is an integral component designed for constructing conveyor sections and other structural applications. This support profile, made from non-rusting steel, ensures durability and longevity in various environments. Characterized by its open construction, the profile allows for easy removal of dirt and foreign particles, maintaining cleanliness in operational settings. The product features an area moment of inertia in the y-direction (ly), x-direction (lx), and comes with a standard length delivery unit that contributes to its rigidity and stability when used in structural frameworks. The weight and mass specifications ensure that it can support appropriate loads without compromising structural integrity. It is part of Productgroup ID, which signifies its categorization within a specific range of Bosch Rexroth products. The SUPPORT.STRUCTURE 160-320+ STS 12X3024 is versatile with elongated holes for attaching various accessories such as drivereturn units, curves, lateral guides, leg sets, among others. This feature facilitates easy assembly and flexibility in application. For sizes above 160, the addition of a support profile becomes necessary to enhance stability; this profile can be fastened using plug-through stainless steel T-nuts provided for secure connections. This Bosch Rexroth support profile maintains consistency across all sizes with the same cross-section profile dimensions. However, it is important to note that MGE T-nuts are not compatible with the STS section profile system. The product's design ensures simple cleaning processes due to its open section profiles which require two halves connected by cross connectors to form a complete section. Overall, this support structure serves as a standard element for secure connection of accessory parts to the section profile and is essential for constructing robust conveyor systems or other related applications where structural integrity is paramount.
