CASTER WHEEL D80 F ESD VPA

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CASTER WHEEL D80 F ESD VPA (3842547836) is a high-quality wheel designed to provide mobility solutions for various applications. This caster wheel features a diameter of 80mm and is constructed with solid rubber, which offers good deformation elasticity, ensuring that the wheel does not permanently flatten when passing over edges or if left stationary for extended periods. It is particularly suitable for use in electrostatic discharge (ESD) sensitive areas, as it meets the conductive material requirements specified in DIN EN standards with a conduction resistance of ≤ 10^7 Ohm. This versatile wheel is equipped with a lock feature (LR with lock), which can prevent both rolling and turning, providing stability when needed. The product can be mounted either in the profile slot or through the central hole, though additional accessories are required. For central hole assembly, thread cutting M8 is necessary for profile finishing. The CASTER WHEEL D80 F ESD VPA is part of Productgroup ID and comes in packaging units designed to accommodate the force F specifications. Its dimensions include a height (h) specification and it has an overall weight of . The wheel requires specific accessories for proper installation: Screw M8x20 ISO 7380 for fastening to the profile core at a tightening torque of 17 Nm, and a bearing ring if a cover cap with hole is used. For securing the wheel, additional fastening materials such as square screw M8x20 and hexagon nut DIN M8 are included. With excellent running properties, this caster wheel from Bosch Rexroth provides mobility solutions that can be tailored to various uses within different environments while ensuring safety and compliance in ESD-sensitive areas.
