PIPE 48,3X1,5 6X3000MM

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth PIPE 483X15 6X3000MM (Material Number 3842533901) is a versatile and robust conveyor system component designed for efficient material handling and easy integration into various industrial environments. This tube, with its diameter of 48.3mm and length of 3000mm, is engineered to facilitate the construction of conveyor supports with minimal screwed connections, enhancing the stability and durability of the system. The PIPE's design includes 10 mm profile slots within the workpiece pallet frame, allowing for straightforward attachment of workpiece supports, which can be used in conjunction with AL sections. The product's thoughtful design details enable rapid and simple adjustments to leg sets, ensuring quick setup times and operational flexibility. For optimal performance, the chain conveyor supported by this tube should be placed on the ground using a combination of components: feet available in three different versions (A, B, C), a tube (E), a flange (F) for mounting holders, and a holder (G) for attaching section profiles. The support structure is specifically tailored to accommodate motors/drives using a separate holder (H), crucial for maintaining system integrity. The spacing between supports is recommended to be approximately 2-3 meters apart, depending on factors such as speed, accumulation behavior, and load weight. Notably, these supports are compatible with both aluminum and stainless steel systems. Holder (G) offers versatility as it can be directly connected to a strut profile 60x60 or an S12x30-T50 from the MGE catalog number 3842530236 and is suitable for inclined conveyor sections up to 28 degrees. For safety and maintenance purposes, holder (G) includes drilling aids for attaching additional features like drip trays or guards. When utilizing feet B or C, cross reinforcements are mandatory due to stability requirements. The PIPE's design also prioritizes cleanliness with draining surfaces that facilitate easy cleaning—a critical consideration in many industrial applications.
