ZDC6XP-1X/14M

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth ZDC6XP-1X/14M (0811401208) is a sophisticated hydraulic component designed for precise control of fluid flow within hydraulic systems. This direct operated supply pressure compensator is configured as a 2-way valve and is integral in maintaining consistent flow rates regardless of load changes. The valve achieves this by combining the functions of a throttle valve and a pressure compensator, which collectively work to keep the pressure differential across the measuring throttle constant. The ZDC6XP-1X/14M valve's pressure compensator spring can be set to maintain a Δp ranging between 8 and 25 bar, ensuring that the flow rate remains steady even when system pressures fluctuate. When paired with a proportional directional valve, this unit transforms into an effective flow control valve that can handle fluid movement in two directions. Designed with versatility in mind, it features a sandwich plate design and conforms to DIN 24340 form A porting pattern. It also includes load compensation capabilities in channel P → A or P → B through an installed shuttle valve. The device ensures efficient operation when dealing with pulling loads during mass deceleration by recommending the use of counterholding valves. The Bosch Rexroth ZDC6XP-1X/14M is particularly suitable for applications where precise fluid control is essential and where varying loads could otherwise affect performance. Its robust design allows it to be effectively integrated into various hydraulic circuits, enhancing overall system reliability and responsiveness.
