INTERFACE MODULE R-IB IL AI 2/SF-230-PAC

Manufacturer: Bosch Rexroth

Material #: R911170425

Model : R-IB IL AI 2/SF-230-PAC

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth R-IB IL AI 2/SF-230-PAC (R911170425) is an advanced analog input module designed for seamless integration within an Inline station. This module is engineered to acquire analog voltage or current signals, ensuring precise data collection and monitoring in various control applications. It supports a range of inputs, including 0...20 mA, 4...20 mA, and 2/4-wire connection techniques, which provides flexibility in connecting different types of sensors and transducers. Additionally, the module can process signals with a voltage range of +/-10V, making it suitable for a broad spectrum of industrial environments. With a dB cutoff frequency at 10 Hz, this input module ensures signal integrity by minimizing noise and interference that could affect the accuracy of data acquisition. The R-IB IL AI 2/SF-230-PAC comes complete with accessories such as a connection plug and labeling field which facilitate easy installation and maintenance. This aids in quick identification and organization within complex control systems. The robust design and compatibility features make this Bosch Rexroth analog input module an essential component for applications requiring reliable analog signal processing. Its ability to handle diverse input ranges coupled with high precision makes it suitable for tasks that demand exactitude in measurement and control operations.

$718.33 USD

More are expected on May 28, 2024

Add to Cart

Status: This product is temporarily out of stock.

Qty: Delivered as early as May 28, 2024 when ordered in

INTERFACE MODULE R-IB IL AI 2/SF-230-PAC

Inline connector

The modular, compact equipment configuration of the I/O systems from Rexroth offers you maximum flexibility for the cost-effective implementation of your individual machine concepts. The I/O modules have robust design and mechanics, are easy to use, have a quick reaction time and are quick to install – both in the control cabinet and in the field. Open communication standards allow you perfect integration of the I/O modules with maximum availability.

Unpacked Weight: 0.094 kg

This module is designed for use within an Inline station. It is used to acquire analog voltage or current signals.

Data Sheet	Download Data Sheet
3D CAD	Download 3D CAD
Manual	Download Manual

Air pressure (operation)	70-106 kPa (up to 3,000 m above sea level)
Air pressure (storage / transport)	70-106 kPa (up to 3,000 m above sea level)
Width	12.2
Productgroup ID	4,6
Height	136.8
International protection code	IP20
Permissible air humidity (storage)	10-95
Permissible air humidity (transport)	10-95
A/D conversion time	120
Number of channels	2
Connection type	Zugfederanschluss
Connection techniques	2-, 3-Leitertechnik
Depth	71.5
Weight	0.094
Ambient temperature (during operation)	-25-55
Ambient temperature (storage and transport)	-25-85
Conductor cross-section	Rigid: 0.2-1.5 mm²,Flexible: 0.2-1.5 mm²,AWG: 24 ... 16

General data

Type		R-IB IL AI 2/SF-230-PAC
Weight 1)	g	68
Operating mode		Process data mode with 2 words
Sensor connection type		2-, 3-wire technology
Sensor supply voltage		Via external power supply unit or via additional segment module with fuse R-IB IL 24 SEG/F
Ambient temperature (operation)		-25 °C ... +55 °C
Ambient temperature (storage/transport)		-25 °C ... +85 °C
Permissible relative humidity (operation)		10 % ... 95 % acc. to DIN EN 61131-2
Permissible relative humidity (storage/transport)		10 % ... 95 % acc. to DIN EN 61131-2
Air pressure (operation)		70 kPa ... 106 kPa (up to 3000 m above sea level)
Air pressure (storage/transport)		70 kPa ... 106 kPa (up to 3000 m above sea level)
Protection type		IP20, IEC 60529
Protection class		III, IEC 61140

1)	Including plug

Connection data

Type		R-IB IL AI 2/SF-230-PAC
Designation		Inline connection plug
Connection type		Tension spring modules
Conductor cross-section solid/flexible/AWG		0.2 mm² ... 1.5 mm² 0.2 mm² ... 1.5 mm² 24 ... 16

Interface local bus

Type		R-IB IL AI 2/SF-230-PAC
Connection type		Data ranking
Transmission speed	kBit/s	500

Inline potentials/performance balance

Type		R-IB IL AI 2/SF-230-PAC
Logic voltage UL	V DC	7.5
Typical current consumption from UL	mA	≈ 45
Peripheral supply voltage UANA	V DC	24
Typical current consumption from UANA	mA	≈ 12
Typical power consumption total	mW	≈ 625

Supply of module electronics and peripherals via bus coupler/power feed module

Type		R-IB IL AI 2/SF-230-PAC
Connectivity technology		Potential jumpers

Analog inputs

Type		R-IB IL AI 2/SF-230-PAC
Number of analog inputs 1)		2
A/D conversion time	µs	≈ 120
Average		Over 16 measured values (deactivatable)
Overvoltage protection		Suppressor diodes in the analog inputs

1)	Analog single-ended inputs

Analog input levels

Type		R-IB IL AI 2/SF-230-PAC
Voltage inputs
Input resistance	kΩ	> 220
Limit frequency (3 dB)	Hz	230
Internal process data update for both channels	ms	< 1.5
Behavior upon sensor interruption		Goes to 0 V
Maximum permissible voltage between analog voltage inputs and analog reference potential	V	± 32
Common mode rejection (CMR)		Min. 90 dB -
Reference: Voltage input signal, valid for permitted DC common mode voltage range	dB	110
Permitted DC common mode voltage for CMR 1)	V	40
Current inputs
Input resistance 2)	Ω	50
Limit frequency (3 dB)	Hz	230
Internal process data update for both channels	ms	< 1.5
Behavior upon sensor interruption		Regulating toward 0 mA or 4 mA
Maximum permissible voltage between analog current inputs and analog reference potential 3)	V	± 5
Common mode rejection (CMR)		Min. 90 dB
Reference: Power input signal, valid for permitted DC common mode voltage range	dB	110
Permitted DC common mode voltage for CMR 4)	V	40
Maximum permitted power	mA	± 100

1)	Between voltage input and FE
2)	Measuring resistance
3)	Equal to 100 mA over the sensing resistances
4)	Between current input and FE

Mechanical tests

Type		R-IB IL AI 2/SF-230-PAC
Shock 1)		Load 15 g for 11 ms, half sinusoidal wave, three shocks per spatial direction and orientationLoad 25 g for 6 ms, half sinusoidal wave, three shocks per spatial direction and orientation acc. to EN 60068-2-27/IEC 60068-2-27

1)	Deviations compared to the common technical data given in the application description DOK-CONTRL-ILSYSPRO***-AW..-DE-P

Conformity

Type		R-IB IL AI 2/SF-230-PAC
Conforms with
Testing of interference immunity acc. to EN 61000-6-2 1)	Discharge of static electricity (ESD)	Criterion B; 6 kV contact discharge; 6 kV air discharge acc. to EN 61000-4-2/IEC 61000-4-2

1)	Deviations compared to the common technical data given in the application description DOK-CONTRL-ILSYSPRO***-AW..-DE-P

Tolerance and temperature behavior for the voltage inputs

		Typical	Maximum
The tolerance specifications refer to the measurement range end value of 10 V
Tolerance at 23 °C
Tolerance via offset	%	± 0.03	± 0.06
Tolerance via gain	%	± 0.05	± 0.1
Differential non-linearity	%	± 0.1	± 0.2
Total tolerance of voltage inputs at 23 ° C Tolerance via offset, gain, and linearity	%	± 0.15	± 0.3
Temperature behavior from -25 °C to +55 °C
Offset drift TKVO	ppm/K	± 6	± 12
Gain drift TKG	ppm/K	± 30	± 50
Total voltage drift TKges = TKVO + TKG	ppm/K	± 36	± 62
Total tolerance of voltage inputs for -25 °C to +55 °C Tolerance via offset, gain, linearity and drift	%	± 0.3	± 0.5

Tolerance and temperature behavior of the power inputs

		Typical	Maximum
The tolerance specifications refer to the measurement range end value of 20 mA
Tolerance at 23 °C
Tolerance via offset	%	± 0.03	± 0.06
Tolerance via gain	%	± 0.1	± 0.1
Differential non-linearity	%	± 0.1	± 0.3
Total tolerance of current inputs at 23 °C Tolerance via offset, gain, and linearity	%	± 0.2	± 0.4
Temperature behavior from -25 °C to +55 °C
Offset drift TKIO	ppm/K	± 6	± 12
Gain drift TKG	ppm/K	± 30	± 50
Total voltage drift TKges = TKIO + TKG	ppm/K	± 36	± 62
Total tolerance of current inputs for -25 °C to +55 °C Tolerance via offset, gain, linearity and drift	%	± 0.35	± 0.6

Additional tolerances under the influence of electromagnetic fields

Type				R-IB IL AI 2/SF-230-PAC
Type of electromagnetic interference	Typical deviation from the measurement range end value
Electro-magnetic fields Field strength 10 V/macc. to EN 61000-4-3/IEC 61000-4-3	Voltage input	Relative	%	< ± 2
	Voltage input	Absolute	mV	< ± 200
	Current input	Relative	%	< ± 2
	Current input	Absolute	μA	< ± 400
Line-fed disturbances III (test voltage 10 V)acc. to EN 61000-4-6/IEC 61000-4-6	Voltage input	Relative	%	< ± 1
	Voltage input	Absolute	mV	< ± 100
	Current input	Relative	%	< ± 1
	Current input	Absolute	μA	< ± 100
Fast transient disturbances (burst) supply 4 kV, input 2 kVacc. to EN 61000-4-4/IEC 61000-4-4	Voltage input	Relative	%	< ± 1
	Voltage input	Absolute	mV	< ± 100
	Current input	Relative	%	< ± 1
	Current input	Absolute	μA	< ± 100

Electrical isolation/insulation of the voltage ranges

Type		R-IB IL AI 2/SF-230-PAC
Common potentials
24 V main voltage UM, 24 V segment voltage US and GND are on the same potential. FE represents a separate potential area.
Separate potentials in the system of bus coupler/feed module and I/O module
Test distance		Test voltage
5 V supply incoming remote bus/7.5 V supply (bus logic)		500 V AC, 50 Hz, 1 min.
5 V supply to further remote bus/7.5 V supply (bus logic)		500 V AC, 50 Hz, 1 min.
7.5 V supply (bus logic), 24 V supply UANA/peripherals		500 V AC, 50 Hz, 1 min.
7.5 V supply (bus logic), 24 V supply UANA/function earth		500 V AC, 50 Hz, 1 min.
Peripherals/function earth		500 V AC, 50 Hz, 1 min.

Error messages to the higher-level control or computer system

Type		R-IB IL AI 2/SF-230-PAC
Error message		Upon failure of the internal voltage supply Upon peripheral / user error: Error signal via input process data

Approvals
The current approvals can be found at www.boschrexroth.com.

Dimensions

Type		R-IB IL AI 2/SF-230-PAC
A	mm	12.2
B	mm	136.8
C	mm	71.5
Note on dimensions		The depth applies when using a support rail TH 35-7.5 (acc. to EN 60715).
