CAM ROLLER RAIL 20 U &

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CAM ROLLER RAIL (R192311931) is a high-quality linear motion component designed for precision and durability. This cam roller guide rail is part of the UNH series, featuring a U-type width and a standard length with a high profile. The guide rails are constructed from aluminum, providing a lightweight yet robust base, while the shafts are made of corrosion-resistant steel conforming to DIN EN ISO standards, ensuring longevity in challenging environments. The CAM ROLLER RAIL is engineered for easy installation with fastener MA, which allows for bolting from above. This design simplifies assembly and maintenance procedures. The product does not come with a cover but offers standard bores for mounting hardware and accessories. It is delivered as a one-piece unit, eliminating the need for assembly of partial sections. With an operating temperature range of -10°C to +100°C, this guide rail can perform reliably in various industrial settings. Its T-profiled rail systems are made from aluminum profiles and corrosion-resistant steel shafts, suitable for diverse applications requiring precise linear motion. This model has a mass of 1.7 kg/m and features a pitch T guide rail of 80 mm. The recommended rail length formula provided by Bosch Rexroth ensures optimal performance: L = n x T + 80 mm. Furthermore, the maximum operating length Lmax specifies that guide tracks up to 4000 mm are manufactured from one-piece precision steel shafts. The CAM ROLLER RAIL's dimensions include size H profiled rail systems with a weight of 2.5 kg/m and nominal size 20, catering to various application requirements that demand both accuracy and strength in linear guidance systems.
