BALL RUNNER BLOCK CARBON STEEL KWD-015-FKS-C1-H-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-015-FKS-C1-H-1 (R166511322) is a high-precision ball runner block designed for linear motion applications where space constraints are a consideration. This component is part of the Ball Rail Systems that facilitate smooth and accurate linear movements. The runner block body, constructed from unalloyed steel CS, ensures durability and robust performance. It features a low preload (Preload class C) and high accuracy class (H), making it suitable for applications requiring precision positioning. The B.RUNNER BLOCK CS includes a ball chain, which contributes to a reduced noise level and improved travel behavior. The design incorporates an initial lubrication and preservation system, ensuring long-term maintenance-free operation. The runner block is compatible with all SNSSNO ball guide rails, allowing for flexible system integration. This model is characterized by its FKS format, which denotes its flange width, short length, and standard height configuration. It does not come with attachment elements on the left or right front reference edges but does include straight lube connections that are loosely attached. The B.RUNNER BLOCK CS is engineered to handle high torque loads and offers exceptional rigidity in all load directions—this allows for single runner block usage on each rail without compromising system stability. It also provides high load ratings in all four main loading directions. Additional features include optional integrated inductive measuring systems for precise feedback and various sealing options such as standard seal SS, low-friction seal LS, double-lip seal DS, front seals, FKM seals, and cover plate wipers to protect against contaminants. With different preload classes available, this product can be tailored to specific application requirements while maintaining excellent dynamic characteristics essential for high-speed operations.
