BALL RUNNER BLOCK CARBON STEEL KWD-015-FKS-C0-H-1
Manufacturer: Bosch Rexroth
Material #: R166519321
Model : B.RUNNER BLOCK CS KWD-015-FKS-C0-H-1
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-015-FKS-C0-H-1 (R166519321) is a high precision ball runner block designed for linear motion applications requiring compactness and high accuracy. The product features a steel CS runner block body with an FKS format, which denotes a flange width, short length, and standard height. It is distinguished by its high accuracy class H and is preload-free, classified under preload class C. This model does not include a ball chain but comes with initial lubrication and preservation.
The B.RUNNER BLOCK CS has an overall length of . mm and provides interchangeability as it can be combined with guide rails of every accuracy. It is engineered to reduce frictional oscillations and maintain low friction levels, especially under external load conditions. This allows for attachments to be mounted from both above and below the block. Its design ensures maximum precision with a patented entry zone that enhances travel accuracy significantly.
Furthermore, the product supports long-term lubrication over several years thanks to lube fittings with metal threads on all sides. It features integrated all-around sealing for protection against contaminants, ensuring durability and consistent performance. The runner block also boasts high torque load capacity, different preload classes, and high rigidity in all load directions that allow for use with just one runner block per rail.
With the same high load ratings in all four main loading directions, the B.RUNNER BLOCK CS maximizes system rigidity due to its preloaded O-arrangement. An optional integrated, inductive and wear-free measuring system can be added for precise motion control. The dynamic characteristics of this product are excellent, suitable for use on all SN/SNO ball guide rails provided by Bosch Rexroth.
In summary, the Bosch Rexroth B.RUNNER BLOCK CS KWD-015-FKS-C0-H-1 (R166519321) is an advanced linear motion component offering exceptional precision, versatility in mounting options, robust sealing mechanisms, long-term lubrication capabilities, and compatibility with a wide range of guide rails for various industrial applications.
$137.70 USD
More are expected on December 17, 2024
Status: This product is temporarily out of stock.
Qty: Delivered as early as December 17, 2024 when ordered in
