BALL RUNNER BLOCK CARBON STEEL KWC-020-FKN-C1-H-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWC-020-FKN-C1-H-2 (R166381310) is a high-precision ball runner block designed for linear motion applications where space is limited in the upward and longitudinal directions. This runner block features a size 20 format with a flange width, short length, and low height. The body of the runner block is made from unalloyed steel CS, ensuring durability and stability. With a preload class C indicating low preload and an accuracy class H for high accuracy, this product is tailored for applications requiring maximum precision. It does not include a ball chain, which simplifies the design and reduces potential maintenance needs. This model comes preserved but without initial lubrication or attachment elements on either front reference edge. The B.RUNNER BLOCK CS KWC-020-FKN-C1-H-2 boasts an optimized entry zone geometry that increases travel accuracy up to six times compared to standard models. It also offers significantly reduced frictional oscillations and maintains low friction levels under external loads. With metal-threaded lube fittings on all sides and end-face fastening threads for attachments, it provides versatility in various mounting scenarios. This model can be used with all SN/SNO ball guide rails and features integrated all-around sealing for protection against contaminants. Its design allows for long-term lubrication over several years, contributing to reduced maintenance requirements. For applications requiring precise measurement, an optional integrated, inductive, and wear-free measuring system can be added. The dynamic load capacity C of the B.RUNNER BLOCK CS KWC-020-FKN-C1-H-2 is determined based on a 100 km travel as per DIN ISO standards. The static load rating C0 reflects its ability to withstand forces without permanent deformation or failure. In summary, the Bosch Rexroth B.RUNNER BLOCK CS KWC-020-FKN-C1-H-2 (R166381310) is a highly accurate and durable solution for linear motion systems with restricted space availability, providing exceptional precision and reliability in various industrial applications.
