BALL RUNNER BLOCK CARBON STEEL KWD-035-SKS-C1-H-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-035-SKS-C1-H-1 (R16663132Y) is a highly precise ball runner block designed for linear motion applications requiring a compact form factor and high accuracy. This SKS size runner block features a slimline width, short length, and standard height, making it suitable for restricted spaces in both longitudinal and transverse directions. Constructed with unalloyed steel CS, it offers low preload in class C and high accuracy in class H. The runner block is equipped with a ball chain that ensures low noise levels and optimal travel behavior, while the integrated all-around sealing provides protection against contaminants. The device also boasts an initial lubrication and preservation for maintenance-free operation over several years. The optimized entry-zone geometry coupled with a high number of balls reduces the variation in elastic deflection under load. Suitable for all SN/SNO ball guide rails, this Bosch Rexroth runner block has excellent dynamic characteristics due to its design that allows for equal load ratings in all four main loading directions. It features an end-face fastening thread for easy attachment of various components from above, enhancing its versatility. The product's overall length is . mm, ensuring compatibility with various guide rail sizes within each accuracy class due to its limitless interchangeability feature. Additionally, the minimum quantity lubrication system includes an integrated reservoir for oil lubrication, extending the service life of the component. This runner block is pre-lubricated at the factory to reduce installation time and effort. It operates within an ambient temperature range of min ... max °C (admissible for short periods) and has a dynamic load capacity C based on DIN ISO standards. The friction coefficient ranges from , ensuring smooth operation within its specified temperature range. In summary, the Bosch Rexroth B.RUNNER BLOCK CS KWD-035-SKS-C1-H-1 (R16663132Y) offers precision linear motion capabilities with robust construction and long-term reliability for various industrial applications where space is limited but performance cannot be compromised.
