BALL RUNNER BLOCK CARBON STEEL KWD-030-SLS-C1-N-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-030-SLS-C1-N-1 (R162371420) is a high-precision ball runner block designed for linear motion applications that require compactness and robust performance. This runner block is part of the Ball Rail Systems product group and is specifically tailored for use in environments where space is restricted in the transverse direction, yet very high loads are expected. It offers the same high load ratings in all four main loading directions, ensuring versatility and reliability. Its slimline (SLS) format with standard width and height, combined with a long overall length, allows it to fit into tight spaces while providing substantial load support. Made from unalloyed steel CS, it has a low preload class C and standard accuracy class N. Notably, this model does not include a ball chain but comes with initial lubrication and preservation to ensure longevity and reduced maintenance. The B.RUNNER BLOCK CS KWD-030-SLS-C1-N-1 boasts an optimized entry zone geometry which, along with a high number of balls, minimizes variation in elastic deflection. Attachments can be easily mounted from above due to its design, which includes end-face fastening threads. It also features integrated all-around sealing to protect against contaminants and employs a minimum quantity lubrication system with an integrated oil reservoir. This runner block can be used on all SN/SNO Ball Guide Rails from Bosch Rexroth, highlighting its excellent dynamic characteristics and interchangeability within each accuracy class. The capability for long-term lubrication over several years makes it an ideal choice for applications demanding minimal maintenance intervention. Its dynamic load capacity C and static longitudinal moment load capacity ML ensure that it can handle demanding applications with ease. In summary, the Bosch Rexroth B.RUNNER BLOCK CS KWD-030-SLS-C1-N-1 offers exceptional performance for linear motion systems requiring precision, durability, and adaptability in challenging industrial environments.
