BALL RUNNER BLOCK CARBON STEEL KWD-030-SLS-C0-N-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-030-SLS-C0-N-1 (R162379422) is a ball runner block designed for high precision and reliable linear motion in various applications. This runner block features a slimline width, long length, and standard height, providing a compact solution for restricted space applications without compromising load capacity. It is constructed from unalloyed steel CS and comes preload-free (preload class C) with standard accuracy (accuracy class N). The inclusion of a ball chain ensures low noise levels and smooth travel behavior. The B.RUNNER BLOCK CS KWD-030-SLS-C0-N-1 is equipped with initial lubrication and preservation, using Dynalub roller bearing grease to facilitate long-term lubrication over several years. Its design allows for high torque load capacity, optimized entry-zone geometry, and a significant number of balls to minimize variation in elastic deflection. Attachments can be conveniently mounted from above due to the end-face fastening thread provided. This runner block boasts integrated all-around sealing, protecting against contaminants that could reduce service life. A minimum quantity lubrication system with an integrated oil reservoir further enhances its maintenance capabilities. It is compatible with all SN/SNO ball guide rails, offering excellent dynamic characteristics and interchangeability within each accuracy class. The B.RUNNER BLOCK CS KWD-030-SLS-C0-N-1 has been engineered to withstand very high loads in all four main directions of loading and is capable of enduring permissible ambient temperatures ranging from minimum values up to maximum values for short periods. For operations at negative temperatures or specific environmental conditions, consultation is recommended. In summary, the Bosch Rexroth B.RUNNER BLOCK CS KWD-030-SLS-C0-N-1 provides a robust solution for linear motion systems requiring precise movement, adaptability in tight spaces, long-term lubrication capabilities, and compatibility with various guide rails and attachments while maintaining low noise operation and exceptional dynamic performance.
