BALL RUNNER BLOCK CARBON STEEL KWD-035-SLS-C2-X-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-035-SLS-C2-X-1 (R162332820) is a high-precision ball runner block designed for linear motion applications requiring compactness and high load capacity. This model features a slimline width, long length, and standard height format (SLS), constructed from unalloyed steel CS. It is characterized by an extra precision accuracy class (XP) and medium preload class C, ensuring smooth motion with reduced elastic deflection. The runner block is devoid of a ball chain and comes pre-lubricated with roller bearing grease Dynalub for initial use. The B.RUNNER BLOCK CS is notable for its optimized entry-zone geometry which, along with a high number of balls, minimizes variations in elastic deflection under load. This model allows attachments to be mounted from above and includes an all-around sealing system for protection against contaminants. Additionally, it incorporates a minimum quantity lubrication system that has an integrated reservoir for oil lubrication. This runner block boasts excellent dynamic characteristics due to its ability to handle high torque loads efficiently. It can be used with all SN/SNO ball guide rails, offering limitless interchangeability within each accuracy class across the Bosch Rexroth ball guide rail systems. The end-face fastening thread facilitates secure attachment of components. Designed to perform reliably in various environmental conditions, the B.RUNNER BLOCK CS can operate within a permissible ambient temperature range of -10°C to +100°C (short-term operation at these temperatures should be consulted with the manufacturer). The product ensures long-term lubrication over several years and supports different preload classes to accommodate varying application requirements. In summary, the Bosch Rexroth B.RUNNER BLOCK CS KWD-035-SLS-C2-X-1 (R162332820) provides robust performance in linear motion systems where space is limited transversely but requires very high load capacities in all four main loading directions. It offers exceptional precision, interchangeability, and dynamic load handling capabilities suitable for diverse industrial applications.
