BALL RUNNER BLOCK CARBON STEEL KWD-035-SLS-C1-X-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-035-SLS-C1-X-1 (R162331821) is a high-precision ball runner block designed for linear motion applications requiring extra precision and low preload. This runner block is part of the Ball Rail Systems product group and is notable for its slimline width, long length, and standard height format (SLS). It has been crafted from unalloyed steel CS to ensure durability and reliability. The B.RUNNER BLOCK CS boasts an accuracy class XP for extra precision and comes with a low preload class C. It does not include a ball chain but comes with initial lubrication and preservation, utilizing roller bearing grease Dynalub. The runner block body is of the standard version, with an overall length specified by the manufacturer. This product features a straight lube connection that is loosely attached and does not come with attachment elements on either front reference edge. Its interchangeability feature allows it to be combined freely with guide rails across all accuracy classes. The B.RUNNER BLOCK CS is suitable for applications where space is limited in the transverse direction, where very high loads are expected, or where high load ratings are required in all four main loading directions. The design includes optimized entry-zone geometry along with a significant number of balls to minimize elastic deflection variation. Attachments can be mounted from above, and it includes integrated all-around sealing. The runner block also has an end-face fastening thread for attachments and can be used on all SN/SNO ball guide rails. Furthermore, this Bosch Rexroth product offers excellent dynamic characteristics, high torque load capacity, and can accommodate long-term lubrication over several years. It also features a minimum quantity lubrication system with an integrated reservoir for oil lubrication. The Bosch Rexroth B.RUNNER BLOCK CS KWD-035-SLS-C1-X-1 (R162331821) provides robust performance suited to various industrial applications where precision linear movement is essential.
