CLAMPING ELEMENT MK 5505 AK ...

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CLAMPING ELEMENT MK 5505 AK (R161954260) is a high-precision pneumatic clamping unit designed for use with ball rail systems. This component offers dynamic and static stabilization in the axial direction and features a simple mechanical gripping principle that provides an excellent price-performance ratio. The clamping unit is easy to mount and operates using compressed air, which actuates a dual-acting gate valve gear mechanism to press the clamping profiles against the guide rails. Constructed from chemically nickel-plated steel, the housing ensures high axial and horizontal rigidity, contributing to precise positioning and longevity of the unit. The pressure can be continuously adjusted from 2 to 6 bar, catering to various application requirements. Additionally, a preloaded return spring enables short decompression cycles, enhancing the efficiency of operations. The MK 5505 AK has been tested for up to 1 million clamping cycles, showcasing its durability. It is compatible with all SNS ball guide rails and can accommodate various rail profile sizes including Size A, B, E, H, N, and S with corresponding thread diameters for mounting. The permissible ambient temperature range for operation extends from -10°C to +80°C. This clamping element is particularly suitable for applications requiring high dynamics and powerful drive mechanisms due to its use of high-precision linear screw drives. With its robust construction and precise control capabilities, the Bosch Rexroth CLAMPING ELEMENT MK 5505 AK stands out as a reliable solution for enhancing stability in linear motion applications.
