BRAKING ELEMENT KBH 5505 AS1A

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth BRAKING ELEMENT KBH 5505 AS1A (R161954021) is a robust hydraulic braking unit designed for high reliability and performance in clamping and braking applications for profiled rail systems. This heavy-duty component is engineered to fit all SNS ball guide rails, ensuring compatibility across a wide range of linear motion systems. The KBH 5505 AS1A boasts an impressive service life, capable of up to 2 million clamping cycles and up to 250,000 emergency braking operations. Featuring a solid, rigid steel housing that is chemically nickel-plated, the unit offers high durability and corrosion resistance. Its integrated all-around sealing provides protection against contaminants, while the special pressure diaphragm technology ensures maximum functional reliability without pressure losses or leakage. The brake shoes come with integrated positive-locking contact profiles that deliver maximum axial rigidity when engaged. The KBH 5505 AS1A operates using hydraulic pressure of up to 240 bar for clamping and braking with precision. Decompression is achieved swiftly thanks to a pre-tensioned return spring which facilitates short decompression cycles. With its compact design conforming to DIN standards, it can be easily integrated into existing systems. This model also features threaded connections on both sides for the hydraulic connection, making installation straightforward. It has been designed with high positioning accuracy in mind and can release at a pressure of just 50 bar. The KBH 5505 AS1A can operate within a permissible ambient temperature range from -30°C to +80°C, ensuring reliable performance in various working environments. Overall, the Bosch Rexroth BRAKING ELEMENT KBH 5505 AS1A (R161954021) is an essential component for users seeking a dependable solution for precise control in their linear motion applications.
