BALL GUIDE RAIL CARBON STEEL KSA-020-SNS-P-MA-AB

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.GUIDE RAIL CS (R160586232) is a high-precision ball guide rail designed for robust performance and versatility in harsh environments. This guide rail is part of the ball rail systems that facilitate smooth linear motion with maximum rigidity in all load directions, as well as an impressive torque load capacity. It features a slimline width (SNS format), standard height, and normal length, making it suitable for a wide range of applications where space and precision are critical. Crafted from carbon steel CS, the B.GUIDE RAIL CS ensures durability and resistance to wear. The guide rail comes with a cover strip made from corrosion-resistant spring steel compliant with DIN EN standards, which alongside screw-down plastic protective caps at the end faces, provides additional protection against environmental factors. The fastener MA allows for bolting from above, simplifying the installation process. With an accuracy class of precision and designed as a two-piece rail system, this model guarantees precise alignment and movement for machinery components. Its compact strip clamp further enhances its stability. The guide rail's permissible ambient temperature ranges from -10°C to 80°C, accommodating various working conditions; however, consultation is recommended for operation at negative temperatures. The B.GUIDE RAIL CS is also characterized by its length adaptability – with a maximum length (Lmax) of 6 meters for the profiled rail systems – ensuring it can be customized to specific application needs. The product’s mass is 9 kg/meter which contributes to its sturdiness without compromising functionality. In summary, this model's combination of slimline design, precision accuracy class, durable construction materials, and temperature resilience makes it an optimal solution for linear guidance in demanding environments where space efficiency and precise movement are paramount.
