LINEAR-SET LSGOE-A-25-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSGOE-A-25-DD (R106862540) is a high-precision linear motion system designed for various applications that require smooth and accurate linear movement. This linear set is composed of a steel linear bushing and shaft, with an open, adjustable design that allows for fine-tuning to achieve zero-clearance or preloaded guides. It features Bosch Rexroth's Super LB A, which is a spheroidal graphite cast ironsteel super linear bushing with a self-alignment feature, enhancing the performance by accommodating misalignment in the system. Equipped with integrated wiper seals on both sides, the LINEAR-SET LSGOE-A-25-DD ensures contamination protection for the internal components, while also contributing to frictional drags. These drags are dependent on speed and lubrication conditions when the radial load is absent. The set comes clamped to h6 shaft lower limit and can handle dynamic load capacities effectively in its main direction of loading. The unit boasts an impressive static load rating C and can endure maximum accelerations (amax), ensuring reliable operation under various conditions. It operates within a permissible ambient temperature range from -20°C to +80°C without compromising functionality. The outer diameter D of the bushing allows for easy installation into different setups. Designed for longevity, tests have indicated that this model can sustain total travel distances significantly high without failure, although service life may be limited due to increased wear on plastic parts at higher speeds. With speeds up to 5 m/s possible, this LINEAR-SET provides versatility for numerous applications. The product's weight stands at 0.71 kg, offering a sturdy yet manageable component for integration into machinery or equipment. The adjusting screw included in the design facilitates radial clearance adjustments post-installation. Overall, the Bosch Rexroth LINEAR-SET LSGOE-A-25-DD represents a robust solution for those needing precise linear guidance in their mechanical systems or automation projects.
