LINEAR-SET LSAO-A-25-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSAO-A-25-DD (R103762520) is a high-quality linear motion system designed for applications requiring precise and smooth linear movement. This product features a lightweight precision housing made from aluminum, which houses a super linear bushing A with a self-alignment feature. The set is equipped with external seals and is relubricatable, ensuring long-term performance and ease of maintenance. The LINEAR-SET LSAO-A-25-DD comes with a shaft diameter of 'd' and includes two seals to protect against contaminants. The set is secured by a grooved taper pin, providing stability and security in its application. The standard version of this linear set offers an optimal balance between performance and durability. This model has been engineered to handle dynamic load capacities effectively, with specific ratings for various sizes (V, E, H, N, M). It also specifies the breakaway force for size H and outlines the maximum permissible linear speed (vmax), highlighting that speeds of up to 5 m/s are possible under certain conditions. However, service life may be limited by wear to plastic parts at these higher speeds. The LINEAR-SET LSAO-A-25-DD can withstand maximum accelerations (amax) and operates within a permissible ambient temperature range of -20°C to +80°C. Its outer diameter D corresponds to size H specifications. Moreover, the product has been tested extensively to ensure reliability over significant distances traveled without failure. With its open format and frictional drag considerations detailed for when it's not under radial load, this linear set is suitable for long guides that require shaft support along with high rigidity. Weighing in at 0.3 kg, it offers an efficient solution for various linear motion needs without adding excessive weight to the assembly.
