HOLLOW SHAFT WO-30H7-CR

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth HOLLOW SHAFT WO-30H7-CR (R100103041) is a high-quality precision steel shaft designed for use with linear bushings in various applications requiring precise motion and guidance. The hollow tubular shaft is constructed from heat-treated steel and features a hard chrome plating, providing exceptional corrosion protection and surface hardness. With a shaft diameter d and an optimal surface roughness RA of 0.3 µm, this model ensures minimal friction and wear for smooth operation. The chrome plating thickness of approximately 25 µm achieves a hardness level of around 900 HV, indicating a durable exterior capable of withstanding rigorous use. The maximum usable length Lmax of the shaft is determined by the specific application requirements, while the mill-cut length L allows for customization to meet individual needs. This particular version of the precision steel shaft falls under the Hohlwelle Series within Bosch Rexroth's product group ID for precision steel shafts. It boasts excellent mechanical properties, including a minimum hardness depth of 0.6 mm and a straightness tolerance that adheres to ISO standards, ensuring reliable performance in precise linear motion setups. The HOLLOW SHAFT WO-30H7-CR maintains strict tolerance grades with h7 for the shaft diameter, ensuring compatibility with corresponding linear bushings and facilitating ease of assembly. Its cylindricality tolerance ensures uniformity along the length of the shaft, contributing to consistent motion control. With its robust construction and meticulous design specifications, this model is an ideal component for creating efficient and accurate linear guide systems in various applications demanding high levels of precision and durability.
