CARRYING PLATE LWT800XBWT480X19,05
Manufacturer: Bosch Rexroth
Material #: 3842548410
Model : CARRYING PLATE LWT800XBWT480X19,05
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CARRYING PLATE LWT800XBWT480X1905 (3842548410) is a robust and versatile component designed for high load applications involving large workpiece pallets. This universal aluminum carrying plate is engineered to support self-assembly by customers, allowing for customization to meet specific product support or adaptation requirements. It comes completely drilled and ready for assembly, offering convenience and saving time during the setup process.
The carrying plate boasts two thickness options: one with a dimension of dPL = 4.5 mm and another at dPL = 6.5 mm, providing flexibility to cater to different needs within various applications. It is compatible with the WT H workpiece pallet kit, ensuring seamless integration with existing systems or setups.
With its aluminum construction, the carrying plate offers a combination of strength and lightness, resulting in a weight of 3.2 kg that contributes to its easy handling without compromising on durability. The dimensions of the product are optimized for practicality, featuring a workpiece pallet total weight capacity (mG) that accommodates significant loads, a length (lWT) tailored for substantial workpiece pallets, and a flatness specification that ensures stability and precision in use.
Designed with standard sizes in mind for broad compatibility, this carrying plate is an ideal solution for those looking to configure their workpiece pallets individually while having access to a range of frame modules, wear pads, positioning bushings, and fastening elements necessary for complete customization. Whether it's utilized in manufacturing environments or other settings requiring reliable material handling solutions, the Bosch Rexroth CARRYING PLATE LWT800XBWT480X1905 stands out as an efficient choice for enhancing productivity and performance in operations involving large workpiece handling.
$994.31 USD
More are expected on December 17, 2024
Status: This product is temporarily out of stock.
Qty: Delivered as early as December 17, 2024 when ordered in
Aluminum carrying plate
No production drawing
|
