CARRYING PLATE LWT640XBWT640X19,05
Manufacturer: Bosch Rexroth
Material #: 3842548409
Model : CARRYING PLATE LWT640XBWT640X19,05
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CARRYING PLATE LWT640XBWT640X1905 (3842548409) is a high-quality aluminum carrying plate designed for handling heavy loads with large workpiece pallets. This product is ideal for customers looking to self-assemble workpiece pallets tailored to their specific requirements or for those who need to adapt the carrying plate for specialized applications. The plate comes fully drilled and ready for assembly, ensuring a straightforward installation process.
With standard dimensions, this carrying plate offers versatility and can be easily integrated into various configurations. It boasts two thickness options, providing flexibility in terms of load-bearing capacity: one with a thickness of 4.5 mm and another at 6.0 mm. This universal aluminum carrying plate is engineered to work seamlessly with the WT H workpiece pallet kit, enhancing its utility in diverse operational contexts.
The product features include a flatness of 0.1 mm, ensuring stability and precision during use. The material used in its construction is aluminum, which contributes to the overall weight of 6.4 kg, making it relatively lightweight yet robust enough to support substantial weights. Its dimensions are optimized for functionality with a width (bWT) of 640 mm and a length (lWT) of 1905 mm.
Bosch Rexroth has meticulously designed this carrying plate to meet the demands of various applications where high load capacity and customization are crucial. Whether it's for manufacturing industries or other sectors requiring precise material handling solutions, the CARRYING PLATE LWT640XBWT640X1905 stands out as a reliable component that can be configured according to individual needs using additional frame modules, wear pads, positioning bushings, and necessary fastening elements provided by Bosch Rexroth for a complete solution.
$1,038.94 USD
More are expected on June 12, 2024
Status: This product is temporarily out of stock.
Qty: Delivered as early as June 12, 2024 when ordered in
Aluminum carrying plate
No production drawing
|
Width of workpiece pallet |
Length of workpiece pallet |
Dimension |
Dimension |
Dimension |
Dimension |
Dimension |
Dimension |
Dimension |
Dimension |
Dimension |
Dimension |
Dimension |
Dimension |
Dimension |
Dimension |
Dimension |
|
bWT |
lWT |
a1 |
a2 |
a3 |
a4 |
a5 |
a6 |
a7 |
a9 |
a12 |
a13 |
a14 |
a15 |
a16 |
a17 |
c |
|
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
|
400 |
400 |
32,5 |
40,0 |
109,0 |
101,5 |
169,0 |
289,0 |
358,0 |
365,5 |
195,0 |
||||||
|
400 |
480 |
32,5 |
40,0 |
99,0 |
101,5 |
159,0 |
209,0 |
319,0 |
379,0 |
438,0 |
445,5 |
295,0 |
||||
|
400 |
640 |
32,5 |
40,0 |
99,0 |
101,5 |
239,0 |
289,0 |
399,0 |
539,0 |
598,0 |
605,5 |
435,0 |
||||
|
400 |
800 |
32,5 |
40,0 |
99,0 |
101,5 |
209,0 |
319,0 |
369,0 |
479,0 |
589,0 |
699,0 |
758,0 |
765,5 |
595,0 |
||
|
480 |
480 |
32,5 |
40,0 |
99,0 |
101,5 |
159,0 |
209,0 |
319,0 |
379,0 |
438,0 |
445,5 |
275,0 |
||||
|
480 |
640 |
32,5 |
40,0 |
99,0 |
101,5 |
239,0 |
289,0 |
399,0 |
539,0 |
598,0 |
605,5 |
435,0 |
||||
|
480 |
800 |
32,5 |
40,0 |
99,0 |
101,5 |
209,0 |
319,0 |
369,0 |
479,0 |
589,0 |
699,0 |
758,0 |
765,5 |
595,0 |
||
|
640 |
640 |
32,5 |
40,0 |
99,0 |
101,5 |
239,0 |
289,0 |
399,0 |
539,0 |
598,0 |
605,5 |
435,0 |
||||
|
640 |
800 |
32,5 |
40,0 |
99,0 |
101,5 |
209,0 |
319,0 |
369,0 |
479,0 |
589,0 |
699,0 |
758,0 |
765,5 |
595,0 |
||
|
640 |
1040 |
32,5 |
40,0 |
99,0 |
101,5 |
269,0 |
439,0 |
489,0 |
599,0 |
769,0 |
939,0 |
998,0 |
1005,5 |
835,0 |
||
|
640 |
1200 |
32,5 |
40,0 |
99,0 |
101,5 |
239,0 |
379,0 |
519,0 |
569,0 |
679,0 |
819,0 |
959,0 |
1099,0 |
1158,0 |
1165,5 |
995,0 |
|
800 |
800 |
32,5 |
40,0 |
99,0 |
101,5 |
209,0 |
319,0 |
369,0 |
479,0 |
589,0 |
699,0 |
758,0 |
765,5 |
595,0 |
||
|
800 |
1040 |
32,5 |
40,0 |
99,0 |
101,5 |
269,0 |
439,0 |
489,0 |
599,0 |
769,0 |
939,0 |
998,0 |
1005,5 |
835,0 |
||
|
800 |
1200 |
32,5 |
40,0 |
99,0 |
101,5 |
239,0 |
379,0 |
519,0 |
569,0 |
679,0 |
819,0 |
859,0 |
1099,0 |
1158,0 |
1165,5 |
995,0 |
|
1040 |
1040 |
32,5 |
40,0 |
99,0 |
101,5 |
269,0 |
439,0 |
489,0 |
599,0 |
769,0 |
939,0 |
998,0 |
1005,5 |
835,0 |
||
|
1040 |
1200 |
32,5 |
40,0 |
99,0 |
101,5 |
239,0 |
379,0 |
519,0 |
569,0 |
679,0 |
819,0 |
859,0 |
1099,0 |
1158,0 |
1165,5 |
995,0 |
|
1200 |
1200 |
32,5 |
40,0 |
99,0 |
101,5 |
239,0 |
379,0 |
519,0 |
569,0 |
679,0 |
819,0 |
859,0 |
1099,0 |
1158,0 |
1165,5 |
995,0 |
|
Width of workpiece pallet |
Length of workpiece pallet |
Dimension |
Dimension |
Dimension |
Dimension |
Dimension |
Dimension |
Dimension |
Dimension |
Dimension |
Dimension |
Dimension |
Dimension |
Dimension |
Dimension |
|
bWT |
lWT |
b1 |
b2 |
b3 |
b4 |
b5 |
b6 |
b7 |
b11 |
b13 |
b14 |
b15 |
b16 |
b17 |
d |
|
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
|
400 |
400 |
32,5 |
40,0 |
109,0 |
101,5 |
229,0 |
289,0 |
358,0 |
365,5 |
195,0 |
|||||
|
400 |
480 |
32,5 |
40,0 |
109,0 |
101,5 |
229,0 |
289,0 |
358,0 |
365,5 |
195,0 |
|||||
|
400 |
640 |
32,5 |
40,0 |
109,0 |
101,5 |
229,0 |
289,0 |
358,0 |
365,5 |
195,0 |
|||||
|
400 |
800 |
32,5 |
40,0 |
109,0 |
101,5 |
229,0 |
289,0 |
358,0 |
365,5 |
195,0 |
|||||
|
480 |
480 |
32,5 |
40,0 |
99,0 |
101,5 |
159,0 |
269,0 |
379,0 |
438,0 |
445,5 |
275,0 |
||||
|
480 |
640 |
32,5 |
40,0 |
99,0 |
101,5 |
159,0 |
269,0 |
379,0 |
438,0 |
445,5 |
275,0 |
||||
|
480 |
800 |
32,5 |
40,0 |
99,0 |
101,5 |
159,0 |
269,0 |
379,0 |
438,0 |
445,5 |
275,0 |
||||
|
640 |
640 |
32,5 |
40,0 |
99,0 |
101,5 |
239,0 |
349,0 |
539,0 |
598,0 |
605,5 |
435,0 |
||||
|
640 |
800 |
32,5 |
40,0 |
99,0 |
101,5 |
239,0 |
349,0 |
539,0 |
598,0 |
605,5 |
435,0 |
||||
|
640 |
1040 |
32,5 |
40,0 |
99,0 |
101,5 |
239,0 |
349,0 |
539,0 |
598,0 |
605,5 |
435,0 |
||||
|
640 |
1200 |
32,5 |
40,0 |
99,0 |
101,5 |
239,0 |
349,0 |
539,0 |
598,0 |
605,5 |
435,0 |
||||
|
800 |
800 |
32,5 |
40,0 |
99,0 |
101,5 |
209,0 |
319,0 |
429,0 |
589,0 |
699,0 |
758,0 |
765,5 |
595,0 |
||
|
800 |
1040 |
32,5 |
40,0 |
99,0 |
101,5 |
209,0 |
319,0 |
429,0 |
589,0 |
699,0 |
758,0 |
765,5 |
595,0 |
||
|
800 |
1200 |
32,5 |
40,0 |
99,0 |
101,5 |
209,0 |
319,0 |
429,0 |
589,0 |
699,0 |
758,0 |
765,5 |
595,0 |
||
|
1040 |
1040 |
32,5 |
40,0 |
99,0 |
101,5 |
269,0 |
439,0 |
549,0 |
769,0 |
939,0 |
998,0 |
1005,5 |
835,0 |
||
|
1040 |
1200 |
32,5 |
40,0 |
99,0 |
101,5 |
269,0 |
439,0 |
549,0 |
769,0 |
939,0 |
998,0 |
1005,5 |
835,0 |
||
|
1200 |
1200 |
32,5 |
40,0 |
99,0 |
101,5 |
239,0 |
379,0 |
519,0 |
629,0 |
819,0 |
959,0 |
1099,0 |
1158,0 |
1165,5 |
995,0 |
