SUPPORT 120+ AL LEG, SET

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SUPPORT 120+ AL LEG SET (3842546627) is a comprehensive support system designed for chain conveyor applications, providing both stability and versatility in material handling setups. This set includes diecast aluminum holders, galvanized steel fastening materials, and all the necessary components for secure installation. The kit comprises one holder, flange nuts M8, T-bolts M8, a footplate, strut profiles, and caps to facilitate a robust assembly. With its modular design, the SUPPORT 120+ AL LEG SET is capable of ground placement or ceiling suspension of conveyor chains. It features an adjustable height range to accommodate various return chains with adjustments up to 100 mm. The set's flexibility allows it to be used for both ascending and descending conveyor sections by removing centering lugs when needed. The silver-colored diecast aluminum holder ensures durability while maintaining a lightweight structure. It is specifically designed for easy alignment within the slot due to its centering lugs, simplifying the installation process with a plug-in screw connection. Additionally, the holder comes with a drill guide for adding extra holes required for accessories like drip trays or trap guards. This leg set is engineered to support motor drives and can be spaced at intervals dependent on speed requirements, accumulation behavior, and load weights. While primarily intended for aluminum systems (AL), the supports are also compatible with stainless steel systems. The inclusion of various profile sizes enhances its adaptability across different conveyor configurations. Overall, the Bosch Rexroth SUPPORT 120+ AL LEG SET offers a reliable solution for supporting chain conveyors in diverse industrial environments where precision and strength are paramount.
