CARRYING PLATE 640X400X12,7 ALU

$676.61 USD

Add to Cart

Note: Sales tax, shipping, and applicable tariffs will be calculated at checkout.

Status: This product is temporarily out of stock.

Qty: Delivered as early as July 25, 2025 when ordered in

CARRYING PLATE 640X400X12,7 ALU

Carrying plate WT 2, AL 12.7 400/640

Unpacked Weight: 8.6 kg

For self-assembly of workpiece pallets for product support
Completely drilled and ready for assembly
15 standard sizes in steel, 4.8 mm thick, with KTL (cataphoretic primer) coating
10 standard sizes in aluminum, 8 mm thick
13 standard sizes in aluminum, 12.7 mm thick
You will find drilling plans for identification and data storage systems in the RFID systems catalog
Can be combined with frame modules of WT 2 workpiece pallets

Data Sheet	Download Data Sheet
3D CAD	Download 3D CAD

Plate thickness [dPL]	12.7
Productgroup ID	2
Workpiece pallet total weight [mG]	100
Dimension [a]	108.5
Flatness	0.8
Material	Aluminum
Weight	8.6
Notice	with four threaded holes for reinforcing bolts
Workpiece pallet width [bWT]	400
Workpiece pallet length [lWT]	640
