SHAFT WITH SUPPORT WM-20-AS1-H7-

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SHAFT WITH SUPPORT WM-20-AS1-H7 (R101502001) is a high-quality component designed for precision linear motion applications. This product features a shaft support rail made of aluminum, specifically tailored for side mounting with a bore spacing type that facilitates heavy-duty linear guide usage. The rail is paired with a heat-treated steel shaft that ensures durability and resistance to wear under strenuous conditions. The shaft diameter adheres to a precise H7 tolerance, guaranteeing a snug fit with compatible linear bushings. This system is particularly useful for scenarios where long guides or high loads are present, and self-supporting shafts are not viable due to potential warping. With the ability to use interconnecting shafts, the length of the guide can be made unlimited, offering versatility in design and application. Moreover, the support rails provide additional degrees of freedom in the circumferential direction when compared to profiled guide rails, making them an excellent choice for applications prone to substructure imprecisions which could lead to warping in other linear guides. The SHAFT WITH SUPPORT WM-20-AS1-H7 is engineered for compatibility with open linear bushings, allowing for ease of installation and maintenance. Its reference edge simplifies alignment during installation, enhancing overall efficiency and reducing setup time. The product's construction reflects Bosch Rexroth's commitment to producing robust components that meet diverse industrial requirements while maintaining precision and reliability in operation.
