SVRV10-26C-0-N-12DR VENTED SVRV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5635051 (5635051) is a high-performance hydraulic relief valve specifically designed for demanding hydraulic circuits that require rapid response and low hysteresis. This screw-in, cartridge-style valve operates as a pilot-operated, two-stage spool type, effectively serving as a pressure-limiting device. The RV10-26X model blocks flow from port 1 to port 2 until the pressure at port 1 is sufficient to unseat the piloting relief. Once this occurs, the main spool shifts, allowing flow between the ports. Notably, this valve is not suitable for cross-over relief applications. Key features include adjustments that cannot be backed out of the valve and positive stops in adjustment options A, B, and C to prevent spring solidification. The valve is constructed with a hardened spool and cage for enhanced durability and offers optional spring ranges up to 207 bar (3000 psi). It also provides fast and smooth responses to pressure surges while fitting into an industry-common cavity design.
