SVRV10-26C-0-V-0 SV VENTED RELIEF

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5635002V (5635002V) is a screw-in, cartridge-style, pilot-operated (two-stage), spool-type hydraulic relief valve designed to serve as a pressure-limiting device in demanding hydraulic circuits that require fast response and low hysteresis. The RV10-26X model effectively manages pressure by blocking flow from port 1 to port 2 until the pressure at port 1 is sufficient to move the piloting relief off its seat. This action allows the main spool to shift, opening the flow path from port 1 to port 2. It is important to note that this valve is not suitable for cross-over relief applications. Featuring positive stops on adjustment options A, B, and C, it prevents springs from going solid while ensuring adjustments cannot be backed out of the valve. The design incorporates a hardened spool and cage for enhanced durability and long life. With optional spring ranges up to 207 bar (3000 psi), this hydraulic relief valve offers a fast and smooth response to pressure surges, making it an efficient choice for maintaining system integrity. Its compatibility with industry-common cavities further enhances its versatility in various applications.
