RV16-26A-16T-V-06/ RELIEF VALVE
Manufacturer: Hydraforce
Material #: 5623561
Model : RV16-26A-16T-V-06/ RELIEF VALVE
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5623561 (5623561) is a screw-in, cartridge-style, pilot-operated (two-stage), spool-type relief valve designed for use as a pressure-limiting device in demanding hydraulic circuits. This model is particularly noted for its fast response and low hysteresis, making it suitable for applications where precise pressure control is critical. The RV16-26X operates by blocking flow from port 1 to port 2 until the pressure at port 1 reaches a level sufficient to unseat the piloting relief. This action allows the main spool to shift, subsequently opening the pathway between port 1 and port 2. It is important to note that this valve should not be used in cross-over relief applications. The design ensures reliable performance in high-pressure environments, providing an essential component for systems requiring consistent and responsive pressure management.
$211.75 USD
Availability: Backordered
Ships from US Note: Sales tax, shipping, and applicable tariffs will be calculated at checkout.
Qty:
Delivered as early as January 29, 2027
| Ratings: | Pressure Ratings Pressure rating: 275.8 bar (4000 psi) Proof pressure: 620.5 bar (9000 psi) Burst pressure: 1275.5 bar (18500 psi) Crack pressure defined: Pressure evident at 7.6 lpm (2 gpm) Reseat pressure: Nominal 90% of crack Relief pressure range: 27.6 to 344.7 bar (140 to 3500 psi) From zero to maximum control current Flow Ratings Flow rating: 302.8 lpm (80 gpm) At max pressure Maximum internal leakage: 114.7 ml/min (7 in³/min) At port 2 at 85% of crack pressure. Pressure setting below 137.9 bar (2000 psi) 491.6 ml/min (30 in³/min) At port 2 at 85% of crack pressure. Pressure setting above 137.9 bar (2000 psi) Temperature Ratings Operating fluid temperature: -40 to 100 °C (-40 to 212 °F) With buna N seals -26 to 204 °C (-15 to 400 °F) With fluorocarbon seals -54 to 107 °C (-65 to 225 °F) With polyurethane seals Storage temperature: -40 to 70 °C (-40 to 160 °F) Ambient temperature: -40 to 70 °C (-40 to 160 °F) |
| Operating Parameters: | Fluids:
Mineral based or synthetic with lubricating properties Fluid viscosity range: 7.4 to 420 cSt Maximum operating contamination level: 18/16/13 per ISO 4406 |
| Performance: |  |
| Installation Specifications: | Cavity:
VC16-2 16-size-2-way Cavities Cartridge installation torque: 62.7 to 73.4 N-m (46 to 54 ft-lb) H style plug torque: 33.9 N-m (25 ft-lb) Orientation restriction: None |
| Order Code: | POSITION CODE DESCRIPTION RV16-26F-H-J-R/S F Adjustment Option F A 1/4" Hex Allen Head F B 1-1/2" Diameter Aluminum Knob with Aluminum Lock Knob F C 1/4" Hex Allen Head with Cover Cap F F Factory Preset Non-Adjustable F H Factory Preset Hidden Adjustment F L 1/4" Hex Allen Head with Cover Cap and Lockwire Holes H Line Body H 0 No Body H 12T Aluminum SAE 12 H 16T Aluminum SAE 16 H 12TD Ductile Iron SAE 12 H 16TD Ductile Iron SAE 16 H 6B Aluminum BSPP 3/4" (6) H 8B Aluminum BSPP 1" (8) H 8BD Ductile Iron BSPP 1" (8) J Seal J N Buna-N J V Fluorocarbon J P Polyurethane J U PPDI Urethane R Spring R 03 27.6 to 344.7 bar (140 to 300 psi) Spring Range R 06 27.6 to 344.7 bar (230 to 600 psi) Spring Range R 35 27.6 to 344.7 bar (1200 to 3500 psi) Spring Range S Setting S MXXX Spring Setting in XXX bar S XX Spring Setting in XX psi (x 100) |
