HSV12-22-0-U-24EG SOLENOID VALVE

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5541020 (HSV1222X) is a high-performance hydraulic cartridge valve specifically designed for load holding applications requiring low leakage. This 2-way, piloted, poppet-type, normally closed screw-in valve is engineered to block flow from ports 2 to 1 when de-energized, while allowing flow from ports 1 to 2 upon overcoming spring forces, as detailed in its performance graph. When energized, the HSV1222X facilitates bidirectional flow. A notable feature of this model is its manual override operation. In normal (de-energized) conditions, the manual override pin needs to be seated in the lower detent groove. For manual shifting, the operator can push down on the knob and rotate it 180 degrees in either direction. Pulling on the knob when the manual override is actuated allows for increased flow, although this feature is intended primarily for emergency use and not for continuous-duty operations. The HSV1222X includes a continuous-duty rated coil and features a hardened seat that ensures longevity and minimal leakage. It offers optional coil voltages and terminations, efficient wet-armature construction, and cartridges that are voltage interchangeable. The unitized, molded coil design enhances durability and performance under various conditions. Furthermore, this valve includes a waterproof E-Coils option rated up to IP69K, ensuring reliable operation even in demanding environments. All HyPerformance products including this model adhere strictly to NFPA specification T2.6.1., with tests conducted at a verification level of 90% and an assurance level of 99%, highlighting its robustness and reliability in hydraulic applications.
