MR10-31-8T-N MANUAL VALVE

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce MR10-31-8T-N (5313160) is a robust, manually operated directional valve designed for precise control in hydraulic systems. This 3-way, 2-position screw-in cartridge valve allows for selective connectivity between its ports depending on the position of the manual operator, which is not included and must be ordered separately. Specifically, it operates such that in its extreme counterclockwise position, ports 1 and 2 are open while port 3 is closed; a 90-degree clockwise rotation changes this configuration so that ports 1 and 3 are open while port 2 is closed. Transition states see all ports closed. This valve accommodates a maximum internal leakage of 164 ml/min at a pressure of 241 bar (3500 psi), ensuring efficient operation even under high-pressure conditions. It supports a variety of fluids including mineral-based or synthetic hydraulic fluids with lubricating properties, within a viscosity range of 7.4 to 420 cSt. The MR10-31-8T-N can operate effectively within a broad temperature range - from -40 to +100°C with buna N seals, and up to +204°C with viton seals. Designed for heavy-duty applications, it features options like two-position detent or an infinite friction lock (to be ordered separately), an optional lockdown bracket for secure installation, and can be fully pressurized at all ports without risk. The unit weighs approximately 0.15 kg and can be installed into any VC103 cavity without orientation restrictions at a torque between 32.5 to 35.3 Nm. This model's versatility and durability make it ideal for various applications requiring reliable directional control in hydraulic systems.
