EP12-S35TG-0-V-160 LOGIC ELEMENT

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5283042V (5283042V) is a screw-in, cartridge style, pilot-to-close hydraulic directional element designed for robust performance in controlling fluid direction in hydraulic systems. This model operates as a spring-biased blocking valve that shifts to allow full flow from port 1 to port 2 only when the pressure at port 1 exceeds the cumulative pressure of port 3 plus the bias spring pressure value. The valve's design ensures minimal pressure drop across itself, enhancing overall system efficiency. It features an industry-common cavity which allows for easier integration or replacement in various applications without the need for extensive modifications to existing systems. Additionally, the 5283042V offers a manual override option with an 80 psi spring, providing added control flexibility and operational reliability under different conditions. This valve's multiple function-application potential makes it suitable for a wide range of hydraulic tasks, emphasizing its adaptability and utility in specialized hydraulic circuits.
