EPFR50-S35T-0-N-230 PILOTED ELEMENT

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce EPFR50-S35T-0-N-230 (5281146) is a highly specialized hydraulic component designed for efficient flow control in hydraulic systems. This screw-in, cartridge-style, bypass type pressure compensating element is engineered to work with remote fixed or variable orifices to maintain a consistent flow rate, irrespective of variations in load pressure. The operational mechanism includes a spring-biased spool type valve with an internal orifice situated between ports 2 and 3. This configuration allows the valve to divert all flow to the tank when the bias spring pressure plus any pressure rise due to no load flow demand is reached. The device features multiple functionalities within a single cavity design, ensuring high system efficiency and low bleed flow across its operating pressure range. It supports a maximum pressure rating of 345 bar (5000 psi) and accommodates fluid temperatures ranging from -40°C to +100°C with Buna N seals, -26°C to +204°C with fluorocarbon seals, and -54°C to +107°C with polyurethane seals. The EPFR50-S35T-0-N-230 is compatible with mineral-based or synthetic hydraulic fluids that have lubricating properties and operates effectively within a fluid viscosity range of 7.4 to 420 cSt. Designed for ease of installation in industry-common cavity VC10S3, this unit allows for flexible orientation without restrictions and requires specific torque settings during cartridge installation (32.5 to 35.3 Nm). The maximum allowable torque stands at 67.8 Nm. For maintenance or replacement needs, various seal kits such as BUNA N (SK10S3NMM), Fluorocarbon (SK10S3VMM), and Polyurethane (SK10S3PMM) are available along with installation instructions. Overall, the Hydraforce EPFR50-S35T-0-N-230 offers robust performance for maintaining precise control over hydraulic flow in demanding applications, ensuring reliability and efficiency in hydraulic system operations.
