***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce CV10-20-8T-N-05 (5201170) is a screw-in, cartridge-style hydraulic check valve designed for use as a blocking or load-holding device. Engineered for hydraulic systems, it facilitates flow from port 1 to port 2 while normally blocking flow in the opposite direction. This model thrives under a pressure rating of up to 3500 psi and proof pressure of 5075 psi, ensuring robust performance even under high-pressure conditions. The valve features a fully guided check assembly that is spring-biased closed. It remains closed until sufficient pressure at port 1 compels it to open towards port 2. This mechanism is supported by an optional 300 psi bias spring with a tall cap, enhancing its flexibility for backpressure applications. The CV10-20-8T-N-05 boasts a hardened seat for extended life and minimal leakage, ensuring reliability and maintenance ease. Offering compatibility with various seals like Buna N, fluorocarbon, polyurethane, and HNBR, it can operate within a fluid temperature range from -26°C to +204°C depending on the seal material used. Its operational prowess is complemented by maximum internal leakage of just two drops per minute at full pressure, showcasing its efficiency in fluid control. Flow-wise, the valve supports up to 20 gallons per minute (75.8 liters per minute), suitable for a broad range of hydraulic applications. It has no orientation restrictions during installation and fits into industry-standard VC102 cavities making it versatile for various setups. The unit's weight varies slightly based on configuration but remains lightweight at approximately 0.08 kg to 0.12 kg. Overall, the Hydraforce CV10-20-8T-N-05 serves as an essential component in hydraulic systems where precise fluid control and reliable performance are critical requirements.
