CV08-20-0-N-40 CHECK VALVE

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5200110 (5200110) is a screw-in, cartridge-style hydraulic check valve designed for use as a blocking or load-holding device in hydraulic systems. This model, known as the CV0820, facilitates fluid flow from port 1 to port 2 while typically preventing flow in the reverse direction. The valve's operation is contingent upon sufficient pressure being applied at port 1, which compresses a bias spring and allows the check to lift, thus permitting flow to port 2. The fully guided check assembly is spring-biased to remain closed until activated by the required pressure, ensuring quick closing and seating which enhances system responsiveness and efficiency. Key features of the CV0820 include a hardened seat that ensures long life and minimal leakage, underscoring its reliability and maintenance ease in various applications. The availability of optional bias springs provides additional flexibility, allowing for customization according to backpressure requirements of different hydraulic systems. Its compact size allows for easy integration into tight spaces within machinery layouts without sacrificing performance. This combination of features makes the Hydraforce 5200110 particularly suited for sophisticated hydraulic applications where space is at a premium and reliable performance is critical.
