TS12-26A-0-V-24ER PRESSURE

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce TS12-26A-0-V-24ER (5122493V) is a high-accuracy, heavy-duty pressure sensor designed for demanding industrial and off-highway equipment applications. It features a total error band accuracy of 1%, achieved by integrating an advanced ASIC with a stable polysilicon thin-film pressure sensor. The sensor is reverse polarity and miswire-protected, offers broad temperature capability, and has an all-welded pressure construction. It boasts a high EMI/RFI rating and is IP67 ingress rated, ensuring durability in harsh environments. With diagnostic rails at 4.5 V, the sensor ensures reliable performance across a temperature range of -20 to 85\u00b0C (-4 to 185\u00b0F). Additionally, the TS12-26X operates as a screw-in, cartridge-style pilot-operated spool-type relief valve that can be infinitely adjusted using variable electric current. The regulated pressure correlates to the input electrical current, with standard 12 and 24-volt coils available. The valve can relieve at approximately 100 psi when no current is applied and supports an adjustable pressure range from 6.9 to 206.8 bar (100 to 3000 psi) depending on the model code configuration. The valve's flow rating is up to 189 lpm (50 gpm), with a hysteresis maximum of 3% and maximum pilot flow of 0.76 lpm (0.2 gpm). It accommodates operating fluid temperatures from -40 to 100 \u00b0C with Buna N seals or -26 to 204 \u00b0C with Viton seals, ensuring adaptability under various conditions. With a unit weight of 0.56 kg (1.23 lb) and internal wetted surface area of 163 cm\u00b2 (36.8 in\u00b2), this component fits into VC12-2 cavities with specific installation torques for both cartridge and coil nut applications. Optional seal kits and housings are available for customization according to specific needs, making it versatile for various settings requiring precise pressure management solutions.
