The Hydraforce PV70-30BM-0-N-12DG (5111023) is a solenoid-operated, pressure-compensated, spool-type, normally closed, priority-type proportional flow control regulator. This versatile device can also be used as a restrictive type, 2-way pressure-compensated proportional flow regulator when port 2 is blocked. Designed for efficient operation, the valve regulates priority flow out of port 3 with the flow rate directly proportional to the current applied to the solenoid, regardless of system working pressure. Excessive flow bypasses out of port 2 and can be utilized for auxiliary function control; however, care should be taken to avoid blocking this bypass line through external valving. In restrictive mode applications where port 2 is blocked, the flow rate out of port 3 remains proportional to the solenoid current regardless of load pressure at port 3. The PV70-30BM-0-N-12DG features excellent linearity and hysteresis characteristics with a hardened spool and cage for enhanced durability. It offers optional coil voltages and terminations along with an efficient wet-armature construction. The unitized molded coil design ensures waterproofing as standard with an optional manual override feature available. It has a maximum inlet pressure rating of 241 bar (3500 psi) and regulated pressure ratings at ports up to 207 bar (3000 psi). The valve supports various operating fluid temperatures depending on seal materials used and provides robust corrosion protection withstanding up to 960 hours in salt spray per ASTM B117 standards. Additionally, it accommodates mineral-based or synthetic hydraulic fluids within a viscosity range of 7.4 to 420 cSt and maintains an internal leakage rate at port 3 not exceeding 197 ml/min under specified conditions.
