SP16-20Y-0-N-00 SOLENOID VALVE

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce SP16-20Y-0-N-00 (5062004) is a solenoid-operated, 2-port, normally closed, poppet-type proportional screw-in hydraulic cartridge valve. It is specifically engineered for applications requiring low leakage blocking and load-holding capabilities. In its default state, when de-energized, the valve functions as a check valve permitting flow from port 1 to port 2 while preventing flow in the reverse direction. Upon energization, the poppet mechanism lifts to establish a flow path from port 2 to port 1 while significantly restricting flow from port 1 to port 2. This valve features a continuous-duty rated coil and efficient wet-armature construction, with manual override options available. Additionally, it can be equipped with optional waterproof E-Coils that are rated up to IP69K for enhanced durability in harsh environments. The SP16-20Y-0-N-00 is designed to handle a pressure rating of up to 250 bar (3625 psi) and has proof and burst pressure ratings of 344 bar (5000 psi) and 779 bar (11300 psi), respectively. It supports a maximum flow rate of 227.4 lpm (60 gpm) with minimal internal leakage of only 5 drops per minute at rated pressure. The valve exhibits hysteresis levels of up to 5% at certain operational thresholds. Temperature-wise, it operates efficiently with different seal options across a wide range: -40 to 100 \u00b0C with buna N seals, -35 to 204 \u00b0C with fluorocarbon seals, and -54 to 107 \u00b0C with polyurethane seals. It also boasts corrosion protection for up to 960 hours in salt spray conditions as per ASTM B117 standards. This cartridge valve is compatible with mineral-based or synthetic hydraulic fluids possessing lubricating properties within a viscosity range of 7.4 to 420 cSt. It requires installation into VC16-2 cavities using specified torque values for optimal performance without orientation restrictions.
