SV12-P20A-12T-N-115AG-N3 SOLENOID VALVE

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5040163 (5040163) is a solenoid-operated, 2-port, normally closed, poppet-type, screw-in hydraulic cartridge valve. This valve is specifically designed to function as a load-holding or blocking valve in systems that require minimal internal leakage. In its default state when de-energized, the 5040163 acts as a check valve allowing fluid flow from port 1 to port 2 while blocking the reverse flow. Upon energization, the poppet lifts to open the flow path from port 1 to port 2; however, in this mode, the flow from port 2 to port 1 is significantly restricted. The valve features an integral position sensor that provides real-time feedback on whether the valve is shifted or not. It boasts a continuous-duty rated coil and a hardened seat which ensures long life and maintains low leakage levels. The construction of the valve includes efficient wet-armature design and cartridges that are voltage interchangeable which enhance its adaptability across different systems with varying voltage requirements. Additionally, it offers optional coil voltages and terminations to suit diverse operational needs. The unit's waterproof E-Coils are rated up to IP69K ensuring protection against ingress of dust and high-pressure water jets. The design also includes a unitized, molded coil design for robustness along with solenoid tubes and coils that are tested for corrosion resistance with a 96-hour salt-spray rating. These features make the Hydraforce 5040163 an effective solution for hydraulic systems requiring reliable load holding and precise control over fluid flow under various conditions.
