SV12-P20AM-12T-N-24DG-M3 SOLENOID VALVE

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5040155 (5040155) is a solenoid-operated, 2-port, normally closed, poppet-type, screw-in hydraulic cartridge valve. This model is specifically designed to function as a load holding or blocking valve in systems requiring minimal internal leakage. In its default state when deenergized, the 5040155 acts as a check valve allowing hydraulic fluid to flow from port 1 to port 2 while preventing flow in the opposite direction. Upon energization, the valve's poppet lifts to facilitate flow from port 1 to port 2, though flow from port 2 to port 1 is significantly restricted. This model features an integral position sensor that provides real-time feedback on the valve's status, ensuring precise control and monitoring of the system. It boasts a continuous-duty rated coil and a hardened seat that enhances durability and sustains low leakage over its lifespan. The optional coil voltages and terminations offer flexibility for various operational requirements. Additionally, its efficient wet-armature construction along with voltage interchangeable cartridges add to its robustness and versatility. The Hydraforce 5040155 is equipped with waterproof E-Coils rated up to IP69K ensuring protection against ingress of dust and high-temperature high-pressure water jets. Moreover, the unitized molded coil design along with solenoid tubes and coils that are rated for 500-hour salt spray ensures reliability in harsh environments. This combination of features makes it an optimal choice for hydraulic applications demanding reliable load holding or blocking functionality with stringent leakage controls.
