SV12-P20A-12T-V-24DG-M3 SOLENOID VALVE

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5040154V (5040154V) is a solenoid-operated, 3-port, normally closed, poppet-type screw-in hydraulic cartridge valve. It is specifically designed to function as a load-holding or blocking valve in various applications where low internal leakage is crucial. The operation of the 5040154V allows it to act as a check valve when de-energized, facilitating flow from port 1 to port 2 while blocking flow in the reverse direction. Upon energization, the poppet lifts, altering the flow path from port 1 to port 2 and significantly restricting flow from port 2 to port 1. This valve integrates several features enhancing its functionality and longevity in demanding environments. It includes an integral position sensor that provides real-time feedback on the valve's status, indicating whether it has shifted. Its continuous-duty rated coil ensures reliable operation under extended periods of use. The hardened seat within the valve contributes to its long life and maintains low leakage levels critical for efficient operations. Additional notable characteristics include optional coil voltages and terminations that offer flexibility for different system requirements. The efficient wet-armature construction minimizes power loss and maximizes hydraulic efficiency. Moreover, cartridges are voltage interchangeable which facilitates maintenance and upgrades without complete system overhauls. The unitized, molded coil design enhances structural integrity and reliability. For environments requiring robustness against elements, the waterproof E-Coils are rated up to IP69K standards ensuring protection against ingress of dust and high-temperature high-pressure water jets. Lastly, the solenoid tubes and coils are designed to withstand harsh conditions evidenced by their 96-hour salt-spray rating, making them suitable for challenging industrial applications.
