SV10-P21A-0-N-24ER/Z-N3 SOLENOID VALVE

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5020537 (5020537) is a solenoid-operated, 2-port, normally open, poppet-type, screw-in hydraulic cartridge valve. It is specifically designed to function as a load holding or blocking valve in various applications, particularly where low internal leakage is critical. In its default state when de-energized, the SV10P21AX configuration of this model allows hydraulic fluid to flow from port 2 to port 1 while severely restricting flow in the opposite direction. Upon energization, the valve shifts to close off flow from port 2 to port 1; however, flow from port 1 to port 2 becomes possible once the solenoid force is overcome. This model boasts several notable features enhancing its functionality and durability. It includes an integral position sensor that provides real-time feedback on the valve's status, indicating whether it has shifted positions. The continuous-duty rated coil ensures reliable operation even under extended periods of use. The hardened seat within the valve contributes to a prolonged lifespan and maintains low leakage levels critical for efficient operations. Additionally, it offers optional coil voltages and terminations to accommodate varying operational requirements. The construction of the Hydraforce 5020537 incorporates efficient wet-armature design principles, making cartridges voltage interchangeable and ensuring robust performance. The unit also features waterproof E-Coils that are rated up to IP69K, providing superior protection against dust and water ingress under severe conditions. Lastly, its solenoid tubes and coils are treated for maximum corrosion resistance with a 960-hour salt spray rating, emphasizing its suitability for harsh environments.
