SV10-P22AS-0-N-0-N3 SOLENOID VALVE

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5020501S (5020501S) is a solenoid-operated, 2-port, normally closed, poppet-type, screw-in hydraulic cartridge valve. It is primarily designed to function as a load holding or blocking valve in systems that require minimal internal leakage. The operation of the valve is straightforward: when de-energized, the SV10P22AX model acts as a check valve, permitting flow from port 1 to port 2 while blocking the reverse flow. Once energized, the poppet lifts to open the flow path from port 2 to port 1, and also allows flow from port 1 to port 2. This dual functionality enhances its application in various hydraulic circuits. Key features of this model include an integral position sensor that indicates when the valve is shifted, which is crucial for precise control in automated settings. It boasts a continuous-duty rated coil and a hardened seat which ensures long life and maintains low leakage over time. The unit offers optional coil voltages and terminations to accommodate different system requirements. Its efficient wet-armature construction along with voltage interchangeable cartridges add to its versatility and reliability. Additionally, the Hydraforce 5020501S is equipped with waterproof E-Coils that are rated up to IP69K, ensuring performance in harsh environmental conditions. The unitized, molded coil design along with solenoid tubes and coils that are resistant to a 960-hour salt spray further highlight its durability and suitability for rigorous applications. These attributes make it an essential component for ensuring reliable operation in hydraulic systems across various applications.
