SV38-30-6T-V-12DL SOLENOID VALVE

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5003137V (5003137V) is a solenoid-operated, 3-way, direct-acting, spool-type, screw-in hydraulic directional valve designed for high-pressure circuits. This model facilitates precise control over hydraulic flow direction, enhancing the performance and efficiency of various hydraulic systems. The operation of the valve is straightforward: when de-energized, it allows flow from port 2 to port 1 while blocking flow at port 3. Conversely, when energized, the cartridge's spool shifts to open flow from port 3 to port 2 and blocks flow out of port 1. Importantly, while port 1 can be fully pressurized in this configuration, it should not be used as the inlet. This specific design feature ensures the valve’s optimal functionality in designated applications by directing fluid efficiently and safely within a hydraulic circuit. The robust construction of the Hydraforce 5003137V makes it suitable for applications requiring reliable directional control of fluids under high pressure conditions.
