***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce ECDR-0506A-002 (4208560) is a sophisticated electronic driver designed for controlling solenoid-operated proportional valves. This device is equipped with a potent bit processor that enhances its computing capabilities, ensuring efficient and precise control. It features six configurable inputs that can adapt to various settings ranging from digital to analog, making it versatile for different control needs. Additionally, the ECDR-0506A-002 offers five outputs, which include four PWM (Pulse Width Modulation) closed-loop outputs and one PWM open-loop output, with adjustable frequency to suit specific application requirements. This controller is particularly suitable for a broad spectrum of applications such as transmission controls, vehicle traction controls, joystick controls, and harvesting function controls. Its compatibility extends to replacing previous HydraForce models like the EVDR series, offering users an upgrade in performance and functionality. The inclusion of a single CAN bus supports both CANopen and SAE J1939 communication protocols, facilitating seamless integration into existing systems. For ease of use and maintenance, the ECDR-0506A-002 features a red-green LED signal that provides immediate operational status checks. Its robust molded enclosure is designed to resist scratches and withstand harsh environments typically found in industrial applications. Diagnostic capabilities of this controller include internal checks for over/under voltage conditions and coil failure, with automatic safety responses such as shifting to a safe mode when supply voltage falls outside the operational range of 8 Vdc to 32 Vdc. The device can be configured using HydraForce's HFImpulse software—a user-friendly, web-accessible tool that simplifies setting adjustments and monitoring. This tool enhances the usability of the ECDR-0506A-002 by allowing users to tailor its operations according to specific needs without requiring extensive technical knowledge.
