10TDN0400-1X/PWR20A00-V2,2-V-S9 (2 PACK)

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hengst directly.***
The Hengst 10TDN0400-1X/PWR20A00-V2,2-V-S9 (1020465B) is a high-performance hydraulic-tank mounted filter designed for effective filtration of solids from liquids within hydraulic or lubrication systems. This duplex return line filter is engineered for installation on liquid containers, providing robust filtration solutions with its multilayer glass fiber material. The filter's nominal size is 0400 and features an FKM seal designation, ensuring reliable performance under various conditions. It is constructed with aluminum housing and a standard support cage material, offering durability and resistance to environmental factors. The Hengst filter has a bypass cracking pressure of 3.5 bar and can withstand a collapse pressure rating of up to 30 bar. Its mounting configuration is tank top with horizontal port positioning, adhering to SAE port standards with a port designation of 2 1/2'' - 3000psi. The nominal and maximum working pressures are both rated at 10 bar, making it suitable for demanding applications where consistent performance is crucial. Equipped with an optical indicator, this filter allows for easy monitoring of the filtration system's status, with a switching point set at 2.2 bar. The design also incorporates a ball valve change-over design to facilitate seamless operation and maintenance. Certified for HFC/HFA suitability and compliant with DIN24550 standards, the Hengst hydraulic-tank mounted filter meets rigorous industry specifications for quality and reliability in fluid management systems.
